CHB Sundeck Trawler

MODEL - YEAR BUILT 1985 CHB 34 Sundeck Trawler
BUILDER Chien Hwa Boat Manufacturing & Industries LTD - Taiwan
REPORTED DIMENSIONS
-LENGTH OVERALL 37 8 including bow and stern platforms
-LENGTH ON DECK 35 0
-BEAM 12 2 as measured
-DRAFT 4 0 as measured during the haul-out
-DISPLACEMENT 17,500# - 26,000# per research
REPORTED SPEED 7 - 10 MPH
REPORTED TANKAGE Fuel: 400G Water: 200G Holding: 35G
HISTORY OF USE: Vessel reported came from FL, and was kept in a
covered berth on Lake Texoma for 15 years.
Current owner purchased the vessel January
2023
Vessel was sold on Lake Texoma in 2019 and
2013 (Ex: Rascal)
MODIFICATIONS - UPGRADES: 2023: Engines service by Brandon Services
2023 : New bottom paint, new VHF, engine shafts realigned, new cutlass bearings, prop shaft glands repacked, new bilge pump installed, new batteries in carbon monoxide detectors, new fridge installed, fuel tank fuel level sight glass changed, new alternator at starboard engine
2018:
- New interior upholstery
- New batteries
2015:
- New Garmin GPS chart plotter
- New VHF radio
- New aft air conditioner unit
- New transom boarding platform
2014: New anchor windlass and ground tackle
2011: Bottom was peeled, minor blisters repaired; and
epoxy barrier coated
DATE OF BOTTOM PAINT: 2021 on Lake Texoma and in 2024 in Aransas Pass
Galley
Ventilation Satisfactory
Stove - None (microwave)
Refrigeration Dometic model CR-1110 AC - DC mini refrigerator- good
condition, functioned properly
Sink Twin stainless steel sinks with Formica laminate countertops
- good condition
Sink Drain Sinks drain directly overboard at the starboard hullside via a
1 1 - 2 bronze seacock located outboard of the starboard
engine - good condition
Appliances Emerson microwave oven - good condition, functioned
Properly
Toilets (2) Jabsco Quiet Flush 12V macerator type with sea water
flushing - both functioned properly
Plumbing Shields white PVC Sanitation type hose - good condition
Holding Tank: (1) Fiberglass tank - forward center in engine compartment bilge
- Capacity Reported 35 gallons - no label at the tank
Seacocks: Most throughout the vessel appeared to be original Far East
bronze seacocks
- Intake - Forward: 3 - 4 Bronze seacock below the forward cabin berth aft to
port - good condition
- Aft: 3 - 4 Bronze seacock below aft head sink - good condition,
functioned properly
- Discharge None
- Sink Drains - Forward: Sink drains overboard at port hullside forward to port in
the engine compartment (1 1 - 2 bronze seacock) - fair condition,

- Aft sink drains directly overboard via a 1 1 - 2 bronze ball-valve
located immediately outboard of the aft toilet - good condition,
functioned properly
Shower - Aft: Walk-in stall - good condition, functioned properly
- Forward - no stall; use a handheld wand - functioned properly
Water Tank: (2) Aluminum tanks (appeared to be retrofit) - side-by-side,
below aft cabin berth
- Capacity 200 Gallons reported - no label at tanks
- Accessibility Good
- Plumbing Reinforced plastic hose - good condition
- Deck Fills (2) At port and starboard aft corners of the raised aft sundeck -
both clearly labeled Water
- Ventilation Tanks each vent overboard at the transom corners - satisfactory
Pressure System ShurFlo 45# PSI 12VDC pressure pump with accumulator
(forward of starboard engine) - good condition, functioned
properly
Water Heater Rheem steel 10 gallons 120VAC water heater (inside the locker
below forward cabins starboard hanging locker) - good
condition, functioned properly
Fuel Type Diesel
Fuel Tanks: (2) Mild steel tanks (appeared original) - outboard aft to port
and starboard in the engine compartment
- Capacity Reported 400 gallons total - no labels at tanks
- Accessibility Extremely limited - covered with sound insulation
